Pacific 565
Pacific 565 the smallest hard top fishing boat on the market. Ideal vessel for day cruises on the river or on the lake.
Layout
Main characteristics
LoA – 5.65 m
Beam – 2.07 m
Overall height – 1.92 m
Transom height – 510 mm
Hull material – Marine grade aluminum 5083
Bottom – 4 mm
Stiffener structure – 3 mm
Freeboards – 3 mm
Beam – 2.07 m
Overall height – 1.92 m
Transom height – 510 mm
Hull material – Marine grade aluminum 5083
Bottom – 4 mm
Stiffener structure – 3 mm
Freeboards – 3 mm
Deck and superstructure – 3 mm
Deadrise stern – 18
Displacement – 600 kg light weight without engine
Fuel tank – 100 L
Passenger capacity – 6 people
Carrying capacity – 600 kg
Engine power – up to 115 hp
Max. speed – 40 knots.
Deadrise stern – 18
Displacement – 600 kg light weight without engine
Fuel tank – 100 L
Passenger capacity – 6 people
Carrying capacity – 600 kg
Engine power – up to 115 hp
Max. speed – 40 knots.
Standard specification
The hull
- All-welded hull made of aluminum 5083
- Handrails aluminum pipe with a diameter of 32 mm in the bow and stern
- Additional transom for the motor (9.9 hp)
- Welded cups for fishing rods on the hull (12 pcs)
- Self-draining cockpit
- A tank for an aerator in the stern, equipped with a water pump and an overflow system
- Non-slip coating on the midships and swim platforms
- Fuel tank for 250 L. with a fuel level indicator.
- Stainless steel bollard 200 mm. (6 pcs).
- Platform for anodes (2 pcs)
- Platform for echo sounder sensor (2 pcs)
- Transom height XL -630 mm
- The design of the bow platform provides for the installation of a roller and an anchor winch
Painting
- Polyurethane paint
- 2 colors to choose
Windows and door
- Tempered glass 6 mm (8 pcs)
- Sliding windows for shkipper and passenger
- Panoramic hatch 2 pcs., in the cabin roof
- Sliding door to the cabin, equipped with a lock and a door retainer in the open position
Interior
- Sintec carpeting
- Marideck deck covering
- SilverTex soft pads in the wheelhouse
- Captain and passenger chairs with l support and foot cushions, mounted on a shock-absorbing pedestals
- Passengers' seats for 3 persons
- Locker
- Finishing of the ceiling and walls of the wheelhouse with decorative panels covered with marine vinyl
- Polished stainless steel handle in the passenger console
- Furniture fittings made of stainless steel
Steering system
- Steering gear, steering cable
- Premium Italian steering wheel
Electrical systems
- Red/green LED running lights in stainless steel
- Stern light LED in stainless steel
- Circular LED light on a folding stand
- Salon light LED
- Recessed sound signal in chrome
- Captain's windshield wiper - 1
- Electric forced bilge pump 1500 GPH - 1
- Electric automatic bilge pump 1500 GPH - 1
- Drain pump fitting chrome - 2
- Panel with 6 key switches, sockets and voltmeter
Price on request
